Current Injection CT PT Analyzer , Power Transformer Testing Equipment 5KVA

  • 1
  • 2

Brand Name : GFUVE

Model Number : TEST-901

Certification : CE ISO

Place of Origin : CHINA

MOQ : 1 Set

Price : Negotiable

Payment Terms : Western Union, T/T, L/C, MoneyGram

Supply Ability : 200Sets/Month

Packaging Details : Industrial Case

Name : CT PT Ana;yzer

Accuracy : Accuracy

Current Output (AC) : 1000A·5V or 500A·10V

Capacity : 5KVA

Range : 0-1100A

Resolution : 0.1A

Contact Now

1100A larger Primary Current injection CT PT Analyzer for testing Ct and PT

TEST-901 primary current injection test set adopts ARM Chip to control its output process and large capacity of toroidal transformers. It is equipped with LCD display and current meter; it can show primary current value, second current value, turn ratio and the action time. Packing is used as aluminum alloy body with PC panel. TEST-901 is mainly applied to CT turn ratio testing in the power system and contact resistance test which need large current.

High-current generator is a necessary equipment in all walks of life in electrical commissioning needs

large current place, used in power plants, substations, electrical manufacturers and scientific research,

laboratory and other units, belonging to short-term or intermittent working system, It has a small size, light

weight, good performance, easy to use and maintenance features.

PARAMETERS

Electrical parameters　
Accuracy ±0.5%
Power Supply(AC) 220V±10%·25A, 50Hz/60Hz or
110V±10%·50A, 50Hz/60Hz
Current Output (AC) 1000A·5V or 500A·10V
Capacity 5KVA
The current output waveform distortion ≤5%
Dual protection overload electronic protection and software protection
Primary current　
Range 0-1100A
Resolution 0.1A
Accuracy <0.5%
Secondary measurement　
Range 0-6A
Resolution 0.001A
Accuracy <0.5%
Current duration　
1000A range 1000A 2-3minutes
500A 3-6minutes
500A range 500A 2-3minutes
With timer
Range 0.0001～999.99S
Resolution 0.001S
Accuracy <0.5%±5 words
Mechanical parameters　
Dimensions (W×D×H) (mm) 430×260×260
Weight(kg) 25
Environmental conditions　
Temperature -10°C to 40°C
Relative humidity ≤80%

Current Injection CT PT Analyzer , Power Transformer Testing Equipment 5KVACurrent Injection CT PT Analyzer , Power Transformer Testing Equipment 5KVA
